The Internet of Things (IoT) requires sustainable, battery-free power solutions. Micro energy harvesting captures ambient energy to enable self‑powered IoT nodes. Among all available sources, solar energy (photovoltaic harvesting) offers the highest power density and greatest maturity, making it the most practical choice for indoor and outdoor IoT deployments. This review places particular emphasis on recent advances in photovoltaic technologies—especially emerging indoor photovoltaics such as perovskites, dye‑sensitized cells, and organic photovoltaics—while briefly summarizing piezoelectric, thermoelectric, and RF harvesting. Key research opportunities are discussed, including hybrid systems, AI‑driven optimization, and scalable integration.
---
The proliferation of IoT devices—expected to exceed 32 billion by 2030—has intensified the need for maintenance‑free, long‑lasting power sources. Batteries pose logistical, economic, and environmental burdens. Micro energy harvesting, which converts ambient light, vibration, heat, or radio waves into electricity, offers a compelling alternative. Among these, solar energy harvesting stands out for its high power density, technological maturity, and broad applicability. This article provides a focused review of solar‑based micro energy harvesting for IoT platforms, identifying key advances and future research directions.
---
Solar (photovoltaic) harvesting delivers power densities from tens of µW/cm² (indoor fluorescent light) to over 10 mW/cm² (direct sunlight). For indoor IoT—where most connected devices operate—light energy density significantly exceeds that of vibration, thermal gradients, or RF signals. This makes photovoltaic (PV) harvesting the most viable route to energy autonomy in smart homes, offices, and retail environments.
Traditional crystalline silicon solar cells perform well under sunlight but suffer from poor low‑light efficiency. Emerging photovoltaic technologies have transformed indoor energy harvesting:
· Perovskite Indoor Photovoltaics (PIPVs): Power conversion efficiencies (PCE) exceeding 40% under typical 200–1000 lux artificial lighting (fluorescent/LED). Perovskites can be solution‑processed on flexible substrates, enabling lightweight, form‑factor‑adaptable IoT nodes.
· Dye‑Sensitized Solar Cells (DSSCs): Well‑matched to diffuse indoor light, with PCE of 20–30% under 200–1000 lux. DSSCs offer stable performance and aesthetic transparency.
· Organic Photovoltaics (OPVs): Tunable bandgaps, semitransparency, and mechanical flexibility. Recent OPVs achieve >25% efficiency under indoor illumination, making them suitable for wearables and building‑integrated IoT.
An energy harvesting IoT platform requires more than the PV cell alone. Key components:
· Power Management IC (PMIC): Harvested energy is intermittent. Ultra‑low‑quiescent‑current PMICs (e.g., 52 nA) boost and regulate the variable PV output to charge a small buffer battery or supercapacitor.
· Ultra‑low‑power MCU: Microcontrollers operating at tens of µA/MHz and nA in sleep mode enable continuous sensing and transmission.
· Energy buffer: A rechargeable battery or capacitor stores energy to bridge periods of darkness.
· Indoor environmental sensors (temperature, humidity, CO₂) powered solely by office lighting (200–500 lux).
· Smart building controls (occupancy, light switches) using PV‑powered wireless nodes.
· Wearable health monitors with flexible OPV patches harvesting indoor/outdoor light.
---
For completeness, three other modalities are summarized:
· Piezoelectric & Triboelectric Harvesting: Convert mechanical vibrations, pressure, or motion into electricity. Power output ranges from µW to mW. Suitable for industrial machinery monitoring or human motion, but source dependency limits wide IoT adoption.
· Thermoelectric Harvesting (TEGs): Exploit temperature gradients (Seebeck effect). Reliable but low power density (µW/cm² per °C). Useful for pipe monitoring or body‑heat wearables.
· RF Energy Harvesting: Captures ambient radio waves (Wi‑Fi, cellular). Very low power density except very near transmitters. Promising for passive RFID and ultra‑low‑power tags.
None of these match solar’s combination of high power density, wide availability, and technology readiness for most indoor/outdoor IoT scenarios.
Ambient re sources | Features | Transducer | Power Density | Benefits | Drawback | Applications |
Thermal energy | Abundant, Linear, relationship of sensor input and output | TEG | 40 | Clean energy, Constant, efficient. | Low energy, higher cost, and output power depend upon thermal gradient conversion efficiency. | IOT sensors |
Wind energy | Abundant, Linear, Relationship of sensor input and output | Wind Turbines | 197W/m2 | Easily available, low cost | Ideal location in remote sites, turbines produce noise, disturbance for wildlife. | Micro devices |
Physical movement of the human body | Human body vibrations, fully controllable | Piezoelectric | 2 W | Available | Energy is harvested only with body movement. | Low power electronics |
6.63W/m2 | Clean energy, low cost, low maintenance | High initial cost, space requirement, transportation in installation. | IOT Applications | |||
Vibrational Energy | Abandant, linear | PZT | 1000W/cm3 | Predictable, reliable, | Sometimes cost high, difficult to design small converters. | Ultra-low power sensors |
Vehicle Motion | Non-Ambient, | Piezoelectric | 332 | Low cost | Highly variable output | Resistive load |
Human Breathing | Passive power, | Thermal sensor | 1.2m-W/cm | Easily available | – | – |
Radio frequency | Abundant, linear | RF sensors | 0.1m-W/cm2 | Low-cost, environment friendly | Can be harmful for living. power density | Communications |
Despite rapid progress, several challenges remain:
1. Hybrid solar+ systems: Combining PV with a secondary source (vibration or thermal) can ensure 24/7 operation. Intelligent power combiner circuits and energy management algorithms are needed.
2. AI‑assisted material discovery: Machine learning can accelerate the design of perovskite and organic PV materials with optimal bandgaps for specific indoor light spectra.
3. Durability and standardization: Emerging PV technologies must demonstrate long‑term stability (>10 years) under real indoor conditions. Standardized testing protocols for energy harvesting IoT modules are lacking.
4. Ultra‑low‑power duty‑cycled operation: Optimizing sensing, processing, and wireless transmission (e.g., LoRa, BLE) to match the intermittent solar profile remains a system‑level challenge.
5. Moisture and multi‑source: New modalities like moisture‑enabled generation (MEG) are emerging; hybrid solar‑moisture harvesters could be explored for high‑humidity IoT environments.
---
5. Conclusion
Micro energy harvesting is essential for sustainable IoT growth. Solar energy harvesting—particularly using emerging perovskite, DSSC, and organic photovoltaics—offers the highest practical power density and has demonstrated self‑powered operation of numerous indoor IoT devices. Other technologies (piezoelectric, thermoelectric, RF) serve niche applications but cannot match solar’s broad applicability. Future research should focus on hybrid architectures, AI‑driven design, long‑term reliability, and system‑level co‑optimization. With continued innovation, solar‑powered IoT platforms will become the standard for billions of connected devices.
---
Suggested short references (example format)
· N. Li et al., “Advances in perovskite indoor photovoltaics,” Mater. Today, 2025.
· A. S. K. et al., “Indoor energy harvesting: DSSCs and OPVs for IoT,” IEEE Access, vol. 13, 2025.
· Market report: “Micro Energy Harvesting Market 2026–2034,” 2026.
